316 Stainless Steel Mesh

Product Description:

316 stainless steel mesh is a woven or welded mesh made from AISI 316 austenitic stainless steel, renowned for its superior corrosion resistance, especially in harsh chemical and marine environments. It is the go-to choice when standard 304 stainless steel isn’t resistant enough.

 Key Features of 316 Stainless Steel Mesh:

 Material Composition (UNS S31600 / AISI 316)

– Chromium (16-18%) → Provides oxidation & rust resistance.

– Nickel (10-14%) → Enhances ductility and toughness.

– Molybdenum (2-3%) ⭐ Key Advantage! → Boosts resistance to chlorides, acids, and pitting corrosion.

– Carbon (≤0.08%) → Low carbon improves weldability (316L variant has even lower carbon).

– Iron (Balance) → Maintains structural strength.

Corrosion Resistance (Best in Class for Common Stainless Steels)

✔ Excellent in seawater & salt spray (marine applications).

✔ Resists sulfuric, phosphoric, and acetic acids (chemical processing).

✔ Performs well in chloride-rich environments (unlike 304).

✔ Better than 904L in some cases (but 904L excels in extreme acids).

Temperature Resistance

– Continuous Use: Up to 870°C (1600°F) (similar to 304).

– Not for extreme heat (use 310, 330, or Inconel above 900°C).

Mesh Specifications:

– Weave Types:

  – Plain Weave (most common for filtration).

  – Twill Weave (stronger, smoother surface).

  – Dutch Weave (ultra-fine filtration).

  – Welded Mesh (rigid, structural use).

– Mesh Sizes: From ultra-fine (400+ mesh) to coarse (1/4″ openings).

– Wire Diameter: Adjustable for strength vs. airflow (e.g., thin wires for filters, thick for screens).

 Top Applications of 316 Stainless Steel Mesh:

 Marine & Offshore

– Saltwater filtration, boat screens, underwater components.

– Desalination plants & offshore oil rigs.

 Chemical & Pharmaceutical

– Acid-resistant filters, reactor screens, pharmaceutical sieves.

– PPE equipment (breathing filters, chemical splash guards).

 Food & Beverage Processing

– Brewery filters, dairy processing, food-grade sieves.

– FDA-compliant (non-reactive with food acids).

 Medical & Surgical

– Implantable mesh, sterilization trays, surgical screens.

– Biocompatible (ISO 10993 certified in 316L form).

 Architectural & Decorative

– Balcony screens, façade cladding (coastal areas).

– Art installations (rust-proof in humid climates).

 316 vs. Other Stainless Steel Meshes:

When to Choose 316 Mesh?

– Marine, chemical, or acidic environments.

– Long-term outdoor exposure (coastal areas).

– When 304 isn’t corrosion-resistant enough.

 When to Avoid 316?

– Extreme heat (use 310/330).

– Ultra-high acid resistance needed (904L is better).

  Fabrication & Maintenance Tips:

– Welding: Use 316L filler wire to prevent carbide precipitation.

– Cleaning: Passivate with nitric acid to restore corrosion resistance.

– Avoid Contamination: Keep away from carbon steel tools (prevents rust transfer).

 Standards & Equivalent Grades:

– UNS S31600 (Standard 316)

– UNS S31603 (316L – Low Carbon, better for welding)

– EN 1.4401 (316) / 1.4404 (316L) (European)

– AISI 316 (Common U.S. designation)

Final Conclusion:

316 stainless steel mesh is the gold standard for corrosion resistance in marine, chemical, and medical applications. If you need long-lasting performance in harsh environments, this is the best balance of cost vs. durability.

For even harsher conditions (e.g., sulfuric acid, seawater + heat), consider 904L. For extreme heat (furnaces, exhausts), 310 or 330 is better.
